TJ550
Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products.
key word:
Aibang Machinery | Copper extruder series
Description
| Model | TJ550 |
| Nominal diameter of extrusion wheel (mm) | Φ550 |
| Main motor power (KW) | 450 |
| Blank Diameter (mm) | Φ22 |
| Maximum width of copper bar (mm) | 300 |
| Maximum width of copper rod (mm) | Φ110 |
| Product cross-sectional area (㎜²) | 300-5800 |
| Average production capacity (kg/h) | 2200 |
Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products. These production lines are available with different specifications and can produce yields such as the aluminum tube, copper flat wire, soft aluminum section wire, and the copper busbar and profile. Also available are continuous rotary extrusion equipment for producing aluminum clad steel wires.
