Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products.

key word:

Aibang Machinery | Copper extruder series

Category:

High-speed continuous extrusion machine for flat copper wires and special-shaped conductors

Service hotline：

+8613506124377

Feedback
Contact us

Description

A



Products: all kinds of pure copper or silver copper flat wires, round wires and special-shaped copper materials

I. Technical parameters

(1) Continuous squeeze host parameters:

Host model:

TJ300　

Nominal diameter of extrusion wheel:

300mm

Rated speed:

11.5rpm

Main motor power:

90kw　

(2) Production line parameters

1. Copper rod blank:

diameter:

Ф12.5 mm　

Diameter tolerance:

±0.2mm

Yield strength:

Upstream oxygen-free copper rod 160Mpa

2, Flat wire products:

cross-sectional area range:

8-250mm² (one out of two, or three, 5 mm²)

Maximum width:

50mm

Product performance index:

Comply with GB5585.1-85 standard requirements

3. Average output:

400kg/h　

4. Installed capacity:

380V, 3 phase, 115KVA

5. The amount of overflow:

1-3%

Three. The complete production line unit includes the following equipment:

Pole material pay-off stand

一台　

Copper rod feeding straightening machine

一台　

Copper rod cutting machine

One

Copper continuous extrusion machine

一台　

Cooling and anti-oxidation system

One

meter counting device

二台　

Take-up machine

1 set (1 small set) 　

Electronic control (with touch screen) system

A set of 　

Hydraulic and lubrication system

A set of 　



A

Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products. These production lines are available with different specifications and can produce yields such as the aluminum tube, copper flat wire, soft aluminum section wire, and the copper busbar and profile. Also available are continuous rotary extrusion equipment for producing aluminum clad steel wires.
