LJ300 Aluminum Flat Wire Production Line
LJ300 Aluminum Flat Wire Production Line

LJ300 Aluminum Flat Wire Production Line

Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products.

key word:

Aibang Machinery | Copper extruder series

Category:

Aluminum tube continuous extrusion high-speed machine series

Service hotline：

+8613506124377

Feedback
Contact us

Description

A



Products: various pure aluminum flat wires (tubes) and special-shaped wires

I. Technical parameters

(1) Continuous squeeze host parameters:

Host model:

LJ300　

Nominal diameter of extrusion wheel:

300mm　

Rated speed:

16-20rpm

Main motor power:

110kw

(2) Production line parameters

1. Blank:

diameter:

Ф9.5 mm (clean aluminum pole for electricians)-Ф12mm　

Diameter tolerance:

±0.2mm

Yield strength:

Clean aluminum pole for electrician 90 Mpa

2. Products:

cross-sectional area range:

8-120mm² (Ф6.5-Ф14 mm aluminum tube)

Maximum width:

30mm

3. Average output:

140 kg/h-220 kg/h　

4. Installed capacity:

380V, 3-phase, 150KVA

5. The amount of overflow:

1%

Three. The complete production line unit includes the following equipment:

Pole material pay-off stand

一台　

Blank rod feeding straightening machine

一台　

Brushing machine

One

Ultrasonic cleaner

一台　

Blank rod cutting machine

One

Continuous extruder

一台　

Cooling system

A set of 　

Meter counting device

A set of 　

Sxy800 special take-up machine

Two sets of 　

Electronic control (with touch screen) system

One ​​set

Hydraulic and lubrication system

One ​​set

Ultra-high pressure hydraulic station

One ​​set



A

Aibang Machinery Technology Co., Ltd. is a Chinese manufacturer of continuous rotary extrusion lines for copper and aluminum products. These production lines are available with different specifications and can produce yields such as the aluminum tube, copper flat wire, soft aluminum section wire, and the copper busbar and profile. Also available are continuous rotary extrusion equipment for producing aluminum clad steel wires.
